HPC Fire Key Valves vs. Manual Safety Pilot Valves: How They Work
HPC Fire Key Valve vs. Manual Safety Pilot Valve
Hearth Products Controls (HPC Fire) uses different valve and control configurations depending on the fire feature system. Two configurations covered here are the HPC Key Valve used with CSA Certified Match-Lit Units (MLFPK) and the Manual Safety Pilot Valve used with CSA Certified Push Button Flame Sensing units.
Understanding how these two valve systems operate makes it easier to distinguish their control methods. The Key Valve provides direct manual operation and flame-height adjustment, while the Manual Safety Pilot Valve uses a pilot-lighting sequence that requires the thermocouple to warm before the burner is turned on.
HPC Fire Valve Technology at a Glance
| Feature | HPC Key Valve | Manual Safety Pilot Valve |
|---|---|---|
| Associated system | CSA Certified Match-Lit Units (MLFPK) | CSA Certified Push Button Flame Sensing units |
| Control method | Manual key-valve operation | Manual pilot-valve operation |
| Startup position | Key Valve opened ¼ turn to the ON position | Valve turned to the PILOT position |
| Flame adjustment | Adjustable from low to high | Not specified in the information covered here |
| Thermocouple step | Not stated for this configuration | Hold valve open for a minimum of 20 seconds |
| Shutdown | Return the Key Valve to the closed position | Not specified in the information covered here |
What Is the HPC Fire Key Valve and How Does It Work?
The HPC Key Valve described here is used with CSA Certified Match-Lit Units (MLFPK). It is a manually operated control with a straightforward operating sequence.
To operate the MLFPK configuration, the Key Valve is opened with a ¼ turn to the ON position. The valve also provides control over flame height, allowing adjustment between low and high.
To turn the unit off, return the Key Valve to the closed position.
HPC Key Valve Operation Summary
How Does the HPC Fire Manual Safety Pilot Valve Work?
The HPC Manual Safety Pilot Valve described here is combined with CSA Certified Push Button Flame Sensing units. Unlike the Key Valve configuration, this system uses a pilot-lighting sequence and requires the thermocouple to warm before the valve is moved to the ON position.
Manual Safety Pilot Valve Operating Sequence
HPC Key Valve vs. Manual Safety Pilot Valve
HPC Key Valve
The HPC Key Valve is associated with the CSA Certified Match-Lit Units (MLFPK) and uses direct manual valve control, including low-to-high flame adjustment.
Manual Safety Pilot Valve
The Manual Safety Pilot Valve is associated with CSA Certified Push Button Flame Sensing units and requires the pilot position and thermocouple-warming step before the valve is turned to ON.
Why the Valve Type Matters When Reviewing an HPC Fire Feature
The valve configuration affects how the fire feature is started and controlled. A buyer reviewing an HPC Fire feature should therefore pay attention to whether the system is identified as a Match-Lit configuration using the Key Valve or as a Push Button Flame Sensing configuration using the Manual Safety Pilot Valve.
What is an HPC Fire Key Valve?
The HPC Key Valve described here is a manually operated valve used with CSA Certified Match-Lit Units (MLFPK). It opens with a ¼ turn to the ON position and provides low-to-high flame-height adjustment.
How does an HPC Fire Key Valve control flame height?
The Key Valve can be adjusted between low and high after it is opened. Return the valve to the closed position when turning the unit off.
What is an HPC Manual Safety Pilot Valve?
The Manual Safety Pilot Valve described here is used with CSA Certified Push Button Flame Sensing units. Its startup sequence includes the PILOT position, a thermocouple-warming period, and then the ON position.
How long should the HPC Manual Safety Pilot Valve be held open?
Hold the valve open for a minimum of 20 seconds while the thermocouple heats. After the thermocouple is sufficiently warmed, turn the valve knob to the ON position.
What is the difference between an HPC Key Valve and a Manual Safety Pilot Valve?
The Key Valve uses direct manual operation with the Match-Lit configuration, while the Manual Safety Pilot Valve uses a pilot and thermocouple-warming sequence with the Push Button Flame Sensing configuration. Do not assume the two systems use the same startup procedure.
Do all HPC Fire features use the same valve system?
This article describes two different HPC Fire valve configurations, so the operating method depends on the system being reviewed. Verify the valve and control configuration for the specific fire feature before following either operating sequence.
