Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE
Sierra Flame
SKU: EMERSON-48-DELUXE-NG
- Description
- Features
- Manuals
- Specifications
- Options and Accessories
- Lowest Price Guarantee 💯
- Warranty Details
Description
Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE Review
Want a clean, and lovely addition to your home decor? Check out the Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE now!
The Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE is a slim 48″ wide See-Thru gas fireplace that is just 9″ deep. Featuring a robust flame and a significant heat output at 26,000 BTU’s, the Emerson is a lovely addition to any space. It comes standard in the Deluxe version, and with black fire glass media and deluxe remote control.
A new vertical installation adapter kit is available through the roof applications.
Note: The unit does not come with a fan.
Includes
- Stones
- Remote
Buy the Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE today and enjoy its awesome view in two rooms at the same time!
Features
Features:
- Borosilicate glass
- Just 9” deep
- No fan
- 2 safety screens
- Flush Clean face design
- 26,000 BTU
- Electronic Ignition
- 7-day programmable thermostat deluxe remote
- 7 stage modulating valve (flame control)
- Linear style burner
- NG or LP
- Top vent only
- 2 non-combustible boards
- Steel header
- Black reflective fire glass media
- The dual stainless steel pan burner
Ideal Applications
- New builds & Renovations
- Restaurants
- Commercial Spaces
- Condominiums
Manuals
Manuals:
- Product Brochure for Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE
- Product Specification for Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE
- Product Manual for Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE
- Product Log Placement Guide for Sierra Flame Emerson 48" See-Thru Direct Vent Linear Gas Fireplace EMERSON-48-DELUXE
Specifications
Specifications:
-
Framing Dimensions (Height, Width, Depth) - (in) 51-3/4” x 56” x 8-3/4”
- Viewing Area (Height, Width) - (in) 13” x 41”
- BTU's: (NG) High - 26,000 Low - 16,500
- AFUE / P4 (NG Efficiency) - 65.8% Weight (lbs) 150
- Venting (in)
4" Flex Vent on Exhaust Side
6" Flex Vent on the Air Intake Side -
Ceiling / Mantle Height (in)
Minimum Ceiling Height from top of the unit: 36"
Minimum from Bottom of the fireplace to the mantle: 48"
Dimension
Options and Accessories
Options and Accessories:
Decorative Media Options
- AMSF‐GLASS‐01 – 1 Box includes approx. 5 lbs of 1/4″ reflective fire glass ‐ 1 sq. ft. of media coverage
- Color: ‘Clear’
- AMSF‐GLASS‐02 – 1 Box includes approx. 5 lbs of 1/4″ reflective fire glass ‐ 1 sq. ft. of media coverage
- Color: ‘Light Brown’
- AMSF‐GLASS‐03 – 1 Box includes approx. 5 lbs of 1/4″ reflective fire glass ‐ 1 sq. ft. of media coverage
- Color: ‘Charcoal’
- AMSF‐GLASS‐04 – 1 Box includes approx. 5 lbs of 1/4″ reflective fire glass ‐ 1 sq. ft. of media coverage
- Color: ‘Champagne’
- AMSF‐GLASS‐05 – 1 Box includes approx. 5 lbs of 1/4″ reflective fire glass ‐ 1 sq. ft. of media coverage
- Color: ‘‘Dark Grey'
- AMSF‐GLASS‐06 – 1 Box includes approx. 5 lbs of 1″ Clear ‘Gem’ fire glass ‐ 1 sq. ft. of media coverage ‘clear’
- Color: ‘Clear’
- AMSF‐GLASS‐07 – 1 Box includes approx. 5 lbs of white frosted fire glass ‐ 1 sq. ft. of media coverage ‘white’
- Color: ‘White’
- AMSF‐GLASS‐08 – 1 Box includes approx. 5 lbs of dusty purple frosted fire glass ‐ 1 sq. ft. of media coverage ‘white’
- Color: ‘Dusty Purple’
- AMSF‐GLASS‐09 – 1 Box includes approx. 5 lbs of amber small bead fire glass ‐ 1 sq. ft. of media coverage ‘amber’
- Color: ‘Amber’
- AMSF‐GLASS‐10 – 1 Box includes approx. 5 lbs of small bead fire glass ‐ 1 sq. ft. of media coverage ‘orange’
- Color: ‘Orange’
- AMSF‐GLASS‐11 – 1 Box includes approx. 5 lbs of small “suntea’ bead fire glass ‐ 1 sq. ft. of media coverage ‘suntea’
- Color: ‘Suntea’
- AMSF‐GLASS‐12 – 1 Box includes approx. 5 lbs of small “black’ bead fire glass ‐ 1 sq. ft. of media coverage ‘black’
- Color: ‘Black’
- AMSF‐GLASS‐13 – 1 Box includes approx. 5 lbs of small “sable’ bead fire glass ‐ 1 sq. ft. of media coverage ‘sable’
- Color: ‘Sable’
Designer Media Kits
- DESIGN‐MEDIA‐6PCE
- 6 piece log set with black fire glass, 90 piece pebble, rocks, Embers 1, Embers 2, Embers 3, and Embers 4
- Use With:
- Newcomb
- Palisade
- Emerson
- Langley
Conversion Kit
- Fuel Conversion Kit
- Fireplace insert fuel conversion kit
- Specifically for the Sierra Flame Abbot series
- Convert your fireplace unit to use either natural gas or liquid propane
Venting Components
- EMERTTK46
- Fire stop/wall thimble & horizontal term kit.
- Size: 4 Inch
- Color: Black
- For use with the Sierra Flame Emerson series
- Fire stop and wall thimble with horizontal termination
- Venting Requirements: This unit requires a venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipes that must be used with this unit.
- SF94206410
- 4” X 6” Coaxial Flex, 10’ Length, Emerson Horizontal Termination Not Included - Order EMERTTK46 Horizontal Termination W/Fireplace from Sierra Flame to complete kit.
- Size: 4 Inch
- Color: Stainless Steel
- Vent pipe sealant
- Vent pipe spacer springs
- 10 feet of coaxial flexible pipe length
- 4" x 6" coaxial flexible venting package
- Taped screw pack for securing vent pipe
- Specifically built for venting of the Sierra Flame Emerson series
- Venting Requirements: This unit requires a venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.
- EMERTTRK-ADP
- Through the roof adaptor kit Includes 2 adaptors 4" flex to 6" hard & 6" flex to 6-5/8" hard
- Size: 4 Inch
- One 4" flex to 4" rigid vent adapter
- One 6" flex to 6" rigid vent adapter
- Flexible venting to rigid venting adapters
- Venting Requirements: This unit requires a venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipes that must be used with this unit.
- DURA-FLEX
- Galvanized adaptor to go from flex to hard pipe
- Size: 3 Inch
- Transitional adaptor
- Safely transitions flexible vent pipe to rigid vent sections
- Venting Requirements: This unit requires a venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipes that must be used with this unit.
- SF942064C
- 4" x 6" Flex extension coupler kit 1 each 3" and 1 each 6"
- Size: 4 Inch
- Color: Stainless Steel
- One 4" flexible vent pipe coupler
- One 6" flexible vent pipe coupler
- 4" x 6" flexible vent pipe extension coupler kit
- Specifically built for venting of the Sierra Flame Emerson series
- Venting Requirements: This unit requires a venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipes that must be used with this unit.
